Collaborative Robot CS Series - CS625 Get latest price

Yet, with a dead weight of only 58kg and a compact 240mm footprint (the same as the CS620), this collaborative robot ensures broad versatility on any work floor.

Specification:

• Payload - 25kg
• Radius - 1500mm
• Repeatability - ±0.08mm
• Axis - 6
• IP rating - IP65 (optional IP68)
• Temperature range - -10~50?
• Relative humidity - <90% (non-condensing)
• Typical power usage - 625w
• Tool I/O connector - T1: M8, 8pin; T2: Ø 12.8mm, 4pin
• Tool I/O ports - 4 config. DI, 4 config. DO; 1 AI, 1 AO
• Tool I/O power supply - T1: 0 / 12V / 24V, 3A, 2A, 1A; T2: 24 V, 5A
• Tool I/O communication - RS485, Modbus RTU
• Footprint - Ø 240 mm
• Weight - 58 kg

To contact Elite Oceania Pty Ltd about Collaborative Robot CS Series - CS625 use Get a quote.
