Cabin Tractor | 75Hp 4WD A/C With Industrial Tyres Price Guide: $39,490 Get latest price

Read more...

To contact Nicola's Machinery about Cabin Tractor | 75Hp 4WD A/C With Industrial Tyres use Get a quote.

Main feature:

• Larger size front end loader with heavy duty self-leveling 4in1 bucket
• 3-point linkage quick hitch hooks
• Overall weight 3,820KG
• Front end loader lift capacity 950KG
• Durable industrial tyres offer traction, stability, puncture resistance, and soil protection for both heavy and light tasks
• Industrial tyre size: front 400/60-15.5; rear 600/50-22.5
• Quick release front end loader with euro quick hitch
• Self-leveling 4in1 bucket
• Heavy duty chassis
• 4 cylinder naturally aspirated direct injection diesel engine (no ECU)
• Hydraulic up & down pressure power 3-point linkage (with floating function)
• Additional 3-point linkage control lever at the rear for easier control
• Full LED lights front & rear
• Tinted windows
• A/C cooling & heating
• 4K 360° dash cam with motion detect
• 12 forward + 12 reverse shuttle shift
• 4WD with diff lock
• Power steering
• Suspension seat
• Dual stage dry clutch
• Oil immersed braking system
• Two speed PTO (540/760 RPM)
• Dual rear remotes

Specifications

Engine

• Engine model: XINCHAI A4K43T75
• Engine type: diesel
• Engine gross power: 55.5KW
• PTO power: 46.9KW
• No. of cylinders: 4
• Rated speed: 2,400RPM
• Battery: 12V
• Alternator: 14V/0.75KW
• Fuel tank capacity: 80L

Drivetrain

• Shuttle transmission: 12F + 12R shuttle shift
• Brakes: oil immersed
• Clutch: dual stage ceramic clutch plate
• PTO: 540/760 RPM

Hydraulic

• Hydraulic remotes: two groups at rear 3PL, one group at FEL
• Lift control type: hydraulic up & down with floating model
• TPL cat: II
• Total hydraulic flow: 72L/MIN
• 3PL cat II lift capacity: 1,500KG max

Dimensions

• Overall weight: 3,820KG
• Overall length (with bucket on the floor): 5,150MM
• Tractor length (without bucket on the floor): 41100MM
• Overall width: 2,150 - 2,250MM (adjustable)
• Overall height: 2,520MM
• Min. ground clearance: 320MM
• FEL Max. reach height: 3,610MM
