Scotpanel Roll Forming Machines

Supplier: Scottsdale Construction Systems
Scotpanel Roll Forming Machines
Scotpanel Roll Forming Machines
Scotpanel Roll Forming Machines
Scotpanel Roll Forming Machines
Scotpanel Roll Forming Machines
Scotpanel Roll Forming Machines
Scotpanel Roll Forming Machines
Scotpanel Roll Forming Machines
Scotpanel Roll Forming Machines

Scotpanel Roll Forming Machines offer unparalleled precision and efficiency, making them ideal for advanced steel framing fabrication.

Description
Documents
Optimised drive and gearbox for enhanced production output.
Receive 1-3 days from order

Overview

The Scotpanel Roll Forming Machines by Scottsdale Construction Systems are designed to elevate your steel framing operations. These machines are compact yet powerful, making them suitable for both factory and mobile light-gauge steel framing businesses. They are widely used globally by homebuilders, commercial framers, and subcontractors.

Key Features

  • Speedier Production: Optimised drive and gearbox combination enhances production output.
  • Self-Adjusting: Automatically adjusts roller pressure for various steel gauges, saving time.
  • Stronger Finish: End-bearing guillotine ensures a flush finish for sturdier construction.
  • Safety First: Enclosed safety with all-over protective panels and a sliding top for access.
  • Continuous Assembly: Optimised fabrication sequencing for maximum output.
  • Universal Coil Size: Uses a common coil for production flexibility and reduced stock SKUs.
  • Guided Input: Enhanced infeed guiding centres the coil for greater stability.
  • Designed to Save: Smart design features deliver faster ROI.

Technical Specifications

Model
5090G1
5090G2
5090G3
Maintenance Kit
1-year
1-year
2-year
Warranty
1-year
1-year
2-year
Top Operating Speed
1,490 m/hr
1,790 m/hr
1,970 m/hr
License
10,000-m Green ScotSteel & ScotRF
Unlimited 1-year Gold ScotSteel & ScotRF
Unlimited perpetual Platinum ScotSteel & ScotRF
C-section Dimensions
90-mm deep, 46-mm wide
90-mm deep, 46-mm wide
90-mm deep, 46-mm wide
Thickness Range
0.55 – 1.1 mm
0.55 – 1.2 mm
0.55 – 1.2 mm
Powertrain
2.2 kW
2.2 kW
4 kW
Gearbox
20:1
12.5:1
12.5:1
Roller Station Set-up
7-roller
7-roller
9-roller
Decoiler
3,300-lb
3,300-lb
6,500-lb
?Model?
5140G1
5140G2
5140G3
Maintenance Kit
1-year
1-year
2-year
Warranty
1-year
1-year
2-year
Top Operating Speed
1,490 m/hr
1,790 m/hr
1,970 m/hr
License
10,000-m Green ScotSteel & ScotRF
Unlimited 1-year Gold ScotSteel & ScotRF
Unlimited perpetual Platinum ScotSteel & ScotRF
C-section Dimensions
140-mm deep, 46-mm wide
140-mm deep, 46-mm wide
140-mm deep, 46-mm wide
Thickness Range
0.55 – 1.1 mm
0.55 – 1.2 mm
0.55 – 1.2 mm
Powertrain
2.2 kW
2.2 kW
4 kW
Gearbox
20:1
12.5:1
12.5:1
Roller Station Set-up
7-roller
7-roller
9-roller
Decoiler
3,300-lb
3,300-lb
6,500-lb
?Model?
7090G1
7090G2
7090G3
Maintenance Kit
1-year
1-year
2-year
Warranty
1-year
1-year
2-year
Top Operating Speed
1,490 m/hr
1,790 m/hr
1,970 m/hr
License
10,000-m Green ScotSteel & ScotRF
Unlimited 1-year Gold ScotSteel & ScotRF
Unlimited perpetual Platinum ScotSteel & ScotRF
C-section Dimensions
90-mm deep, 37-mm wide
90-mm deep, 37-mm wide
90-mm deep, 37-mm wide
Thickness Range
0.55 – 1.1 mm
0.55 – 1.2 mm
0.55 – 1.2 mm
Powertrain
2.2 kW
2.2 kW
4 kW
Gearbox
20:1
12.5:1
12.5:1
Roller Station Set-up
7-roller
7-roller
9-roller
Decoiler
3,300-lb
3,300-lb
6,500-lb
?Model?
7063G1
?7063G2
?7063G3?
Maintenance Kit
1-year
1-year
2-year
Warranty
1-year
1-year
2-year
Top Operating Speed
1,490 m/hr
1,790 m/hr
1,970 m/hr
License
10,000-m Green ScotSteel & ScotRF
Unlimited 1-year Gold ScotSteel & ScotRF
Unlimited perpetual Platinum ScotSteel & ScotRF
C-section Dimensions
63-mm deep, 37-mm wide
63-mm deep, 37-mm wide
63-mm deep, 37-mm wide
Thickness Range
0.55 – 1.1 mm
0.55 – 1.2 mm
0.55 – 1.2 mm
Powertrain
2.2 kW
2.2 kW
4 kW
Gearbox
20:1
12.5:1
12.5:1
Roller Station Set-up
7-roller
7-roller
9-roller
Decoiler
3,300-lb
3,300-lb
6,500-lb
?Model?
7070G1
7070G2
?7070G3?
Maintenance Kit
1-year
1-year
2-year
Warranty
1-year
1-year
2-year
Top Operating Speed
1,490 m/hr
1,790 m/hr
1,970 m/hr
License
10,000-m Green ScotSteel & ScotRF
Unlimited 1-year Gold ScotSteel & ScotRF
Unlimited perpetual Platinum ScotSteel & ScotRF
C-section Dimensions
70-mm deep, 37-mm wide
70-mm deep, 37-mm wide
70-mm deep, 37-mm wide
Thickness Range
0.55 – 1.1 mm
0.55 – 1.2 mm
0.55 – 1.2 mm
Powertrain
2.2 kW
2.2 kW
4 kW
Gearbox
20:1
12.5:1
12.5:1
Roller Station Set-up
7-roller
7-roller
9-roller
Decoiler
3,300-lb
3,300-lb
6,500-lb
?Model?
7076G1
?7076G2?
?7076G3?
Maintenance Kit
1-year
1-year
2-year
Warranty
1-year
1-year
2-year
Top Operating Speed
1,490 m/hr
1,790 m/hr
1,970 m/hr
License
10,000-m Green ScotSteel & ScotRF
Unlimited 1-year Gold ScotSteel & ScotRF
Unlimited perpetual Platinum ScotSteel & ScotRF
C-section Dimensions
76-mm deep, 37-mm wide
76-mm deep, 37-mm wide
76-mm deep, 37-mm wide
Thickness Range
0.55 – 1.1 mm
0.55 – 1.2 mm
0.55 – 1.2 mm
Powertrain
2.2 kW
2.2 kW
4 kW
Gearbox
20:1
12.5:1
12.5:1
Roller Station Set-up
7-roller
7-roller
9-roller
Decoiler
3,300-lb
3,300-lb
6,500-lb
?Model?
7140G1
?7140G2?
?7140G3?
Maintenance Kit
1-year
1-year
2-year
Warranty
1-year
1-year
2-year
Top Operating Speed
1,490 m/hr
1,790 m/hr
1,970 m/hr
License
10,000-m Green ScotSteel & ScotRF
Unlimited 1-year Gold ScotSteel & ScotRF
Unlimited perpetual Platinum ScotSteel & ScotRF
C-section Dimensions
140-mm deep, 37-mm wide
140-mm deep, 37-mm wide
140-mm deep, 37-mm wide
Thickness Range
0.55 – 1.1 mm
0.55 – 1.2 mm
0.55 – 1.2 mm
Powertrain
2.2 kW
2.2 kW
4 kW
Gearbox
20:1
12.5:1
12.5:1
Roller Station Set-up
7-roller
7-roller
9-roller
Decoiler
3,300-lb
3,300-lb
6,500-lb
?Model?
8140G2
?8140G3?

Maintenance Kit
1-year
2-year

Warranty
1-year
2-year

Top Operating Speed
1,490 m/hr
1,490 m/hr

License
Unlimited 1-year Gold ScotSteel & ScotRF
Unlimited perpetual Platinum ScotSteel & ScotRF

C-section Dimensions
140-mm deep, 46-mm wide
140-mm deep, 46-mm wide

Thickness Range
0.75 -1.5 mm
0.75 -1.5 mm

Powertrain
7.5 kW
7.5 kW

Gearbox
63:1
63:1

Roller Station Set-up
14-roller
14-roller

Decoiler
6,500-lb
6,500-lb

Additional Features

  • Double-rivet functionality for enhanced stability.
  • Region-specific service hole punch for versatility.
  • Web notch toolkit included for customisation.
  • Inkjet labelling printer for easy identification.
  • Stud end-bearing toolset for precise construction.
  • Plumbing hole punch toolset for additional utility.
  • Premium cover system with enhanced safety features.
  • TrueTrack reverse lip toolkit for advanced framing options.

Read more...
