The KFS Framemaker Roll Formers are advanced steel framing machines designed for efficient and precise structural light gauge steel (LGS/CFS) fabrication in both commercial and residential applications.

Description
Documents
High-speed structural steel framing with multi-profile automation and precision.

The KFS Framemaker Roll Formers are high-performance machines engineered for the production of load-bearing steel frame components. Ideal for stud and track suppliers, off-site construction, modular and panelised building contractors, and both residential and commercial fabricators, they are optimised for the demands of structural steel framing.

Key Features
  • Proven high reliability and performance speed, processing up to 2,200 m/hr with servo drive and supporting steel coil yield strengths up to 450 MPa and tensile strengths up to 520 MPa.
  • Advanced precision from hydraulic cut-off and punch tools, plus a servo drive system.
  • Efficient process management with an integrated digital batch controller.
  • Multi-profile capability: forms various web widths and flange heights in 0.75mm – 2.7mm steel.
  • Automated feeding, cutting and punching increase productivity.
  • Meets ASTM A1008 and ASTM 653 standards for Grade 33 structural steel.
  • Compatible with leading control software including Strucsoft MWF, ScotSteel, Framebuilder MRD, and Vertex.
KFS Framemaker Models & Key Specifications
Model
Steel Gauge (mm)
Web Width Options (mm)
Flange Width Options (mm)
Warranty
Decoiler Capacity (kg)
Batch Control
1218G1 / 1218G2
1.1 – 2.7
152, 203, 254, 305
51, 63.5, 76, 89
1 (G1) / 2 (G2) years
2,950 (G1), 4,500 (G2)
Digital controller / Advanced management option (EclipsePRO)
1420G1 / 1420G2
0.84 – 1.9
92, 102, 152, 203, 254, 305
41, 51, 63.5
1 (G1) / 2 (G2) years
2,950 (G1, G2)
Digital controller / Advanced management option (EclipsePRO)
1622G1 / 1622G2
0.75 – 1.5
89, 92, 102, 140, 152, 203
41, 51, 63.5
1 (G1) / 2 (G2) years
2,950 (G1), 2,950 (G2)
Digital controller / Advanced management option (EclipsePRO)
Standard Features (model dependent)
  • Multi-profile roll-forming cage with quick-adjustment.
  • Standard or profile-specific shear blade and die kits.
  • Beck Automation SII or AMS advanced control systems.
  • Powered decoiler with automated feed speed control.
  • Flange dimpling punch, web service hole and adjustable punch toolkits for versatile steel processing.
  • Optional inkjet labelling printer, spare parts kit, basic or advanced production management software.
  • All models support SFIA / SSMA / CSSBI standard profiles.

Read more...

To contact Scottsdale Construction Systems about KFS Framemaker Roll Formers use Get a quote.
