UV Printer Machine 200 mm | VersaOBJECT ...

UV Printer Machine 200 mm | VersaOBJECT CO Series

Supplier: Prytec Solutions

Take object customisation to new heights with the VersaOBJECT CO.

Receive 1-3 days from order

Take object customisation to new heights with the VersaOBJECT CO Series of UV flatbed printers. Digital UV printing has never been more versatile and the CO Series is the perfect solution for customising boards, objects up to 200 mm in height and even irregular 3D objects.

The Roland DG CO Series – a cutting-edge line of UV printers designed to elevate your printing and graphics capabilities. These printers are meticulously enhanced to meet the demands of today's sign and graphics providers. Elevate your business with the innovation and reliability of the Roland DG CO Series.

Specifications:

Model		CO-300i-F2	CO-300i-F2A	CO-640i-F2	CO-640i-F3	CO-640i-F4
Printing Method		Piezo ink-jet method
Attachable objects to be printed on	Width	Max. 762 mm (30 in.)	Max. 762 mm (30 in.)	Max. 1,625 mm (64 in.)	Max. 1,625 mm (64 in.)	Max. 1,625 mm (64 in.)
	Thickness	Max. 242 mm (9.5 in.)
	Weight	Max. 100 kq/m2 (0.142 Ib./in2)
Maximum Printing Width/Length		Max. 749 × 1,500 mm (29.4 in. × 59.0 in.)	Max. 749 × 1,500 mm (29.4 in. × 59.0 in.)	Max. 1,612 × 1,500 mm (63.4 in. × 59.0 in.)	Max. 1,612 × 2,500 mm (63.4 in. × 98.4 in.)	Max. 1,612 × 3,050 mm (63.4 in. × 120.0 in.)
Ink	Types	ECO-UV(EUV5) 220 ml cartridge(White) ECO-UV(EUV5) 500 ml cartridge(Cyan, Magenta, Yellow, Black, Red, Orange, Gloss, Primer)
	Colours	Eight colours (Cyan, Magenta, Yellow, Black, Red, Orange, White, Gloss) Seven colours (Cyan, Magenta, Yellow, Black, Red, Orange, White) Seven colours (Cyan, Magenta, Yellow, Black, Red, Orange, White) and Primer Seven colours (Cyan, Magenta, Yellow, Black, Red, White, Gloss) and Primer Six colours (Cyan, Magenta, Yellow, Black, White, Gloss) and Primer Six colours (Cyan, Magenta, Yellow, Black, White, Gloss) Four colours (Cyan, Magenta, Yellow, Black)
Ink-curing unit		Built-in UV-LED lamp
Printing resolution (dots per inch)		Max. 1,440 dpi
Connectivity		Ethernet (100BASE-TX/1000BASE-T, automatic switching)
Power-saving Function		Automatic sleep feature
Power Requirements		230V 16A 2P+E
Power Consumption	During operation (100% Vacuum)	Approx. 1.80 kW	Approx. 0.24 kW	Approx. 1.80 kW	Approx. 2.90 kW	Approx. 2.90 kW
	Sleep mode	Approx. 0.08 kW
Acoustic Noise Level	During operation	80 dB (A) or less	70 dB (A) or less	80 dB (A) or less /td>	90 dB (A) or less	90 dB (A) or less
	During Standby	70 dB (A) or less	60 dB (A) or less	70 dB (A) or less	80 dB (A) or less	80 dB (A) or less
Dimensions (width x depth x height)		1,928 mm × 2,384 mm × 1,469 mm ( 76.0 in. × 93.9 in. × 57.9 in.)	1,928 mm × 2,384 mm × 1,469 mm ( 76.0 in. × 93.9 in. × 57.9 in.)	2,815 mm × 2,384 mm × 1,469 mm ( 110.9 in. × 93.9 in. × 57.9 in.)	2,815 mm × 3,399 mm × 1,469 mm ( 110.9 in. × 133.9 in. × 57.9 in.)	2,815 mm × 3,999 mm × 1,469 mm ( 110.9 in. × 157.5 in. × 57.9 in.)
Weight		487 kg ( 1,074 lb.)	455 kg ( 1,004 lb.)	667 kg ( 1,471 lb.)	863 kg ( 1,903 lb.)	959 kg ( 2,115 lb.)
Environment	During operation(*1)	Temperature: 20 to 32 °C (68 to 89.6 °F), Humidity: 35 to 80 %RH (no condensation)
	Not operating	Temperature: 5 to 40 °C (41 to 104 °F), Humidity: 20 to 80 %RH (no condensation)
Included Items		Power cord, cleaning liquid, drain bottle, User’s Manual, software (VersaWorks, Roland DG Connect), etc.

1 Operating environment (Use the machine in an operating environment within these ranges.)

CO-640

Printable Width 1,612mm
Printable length options 1,500 mm, 2,500 mm, 3,050 mm
Max Print Height 200 mm
Available Ink CMYK, Gloss, White, Red, Orange, Primer
Bed Options Flatbed | Belt1

CO-300

Printable Width 749mm
Printable length options 1,500 mm
Max Print Height 200 mm
Available Ink CMYK, Gloss, White, Red, Orange, Primer
Bed Options Flatbed | Belt1

To contact Prytec Solutions about UV Printer Machine 200 mm | VersaOBJECT CO Series use Get a quote.

Specifications:

Model		CO-300i-F2	CO-300i-F2A	CO-640i-F2	CO-640i-F3	CO-640i-F4
Printing Method		Piezo ink-jet method
Attachable objects to be printed on	Width	Max. 762 mm (30 in.)	Max. 762 mm (30 in.)	Max. 1,625 mm (64 in.)	Max. 1,625 mm (64 in.)	Max. 1,625 mm (64 in.)
	Thickness	Max. 242 mm (9.5 in.)
	Weight	Max. 100 kq/m2 (0.142 Ib./in2)
Maximum Printing Width/Length		Max. 749 × 1,500 mm (29.4 in. × 59.0 in.)	Max. 749 × 1,500 mm (29.4 in. × 59.0 in.)	Max. 1,612 × 1,500 mm (63.4 in. × 59.0 in.)	Max. 1,612 × 2,500 mm (63.4 in. × 98.4 in.)	Max. 1,612 × 3,050 mm (63.4 in. × 120.0 in.)
Ink	Types	ECO-UV(EUV5) 220 ml cartridge(White) ECO-UV(EUV5) 500 ml cartridge(Cyan, Magenta, Yellow, Black, Red, Orange, Gloss, Primer)
	Colours	Eight colours (Cyan, Magenta, Yellow, Black, Red, Orange, White, Gloss) Seven colours (Cyan, Magenta, Yellow, Black, Red, Orange, White) Seven colours (Cyan, Magenta, Yellow, Black, Red, Orange, White) and Primer Seven colours (Cyan, Magenta, Yellow, Black, Red, White, Gloss) and Primer Six colours (Cyan, Magenta, Yellow, Black, White, Gloss) and Primer Six colours (Cyan, Magenta, Yellow, Black, White, Gloss) Four colours (Cyan, Magenta, Yellow, Black)
Ink-curing unit		Built-in UV-LED lamp
Printing resolution (dots per inch)		Max. 1,440 dpi
Connectivity		Ethernet (100BASE-TX/1000BASE-T, automatic switching)
Power-saving Function		Automatic sleep feature
Power Requirements		230V 16A 2P+E
Power Consumption	During operation (100% Vacuum)	Approx. 1.80 kW	Approx. 0.24 kW	Approx. 1.80 kW	Approx. 2.90 kW	Approx. 2.90 kW
	Sleep mode	Approx. 0.08 kW
Acoustic Noise Level	During operation	80 dB (A) or less	70 dB (A) or less	80 dB (A) or less /td>	90 dB (A) or less	90 dB (A) or less
	During Standby	70 dB (A) or less	60 dB (A) or less	70 dB (A) or less	80 dB (A) or less	80 dB (A) or less
Dimensions (width x depth x height)		1,928 mm × 2,384 mm × 1,469 mm ( 76.0 in. × 93.9 in. × 57.9 in.)	1,928 mm × 2,384 mm × 1,469 mm ( 76.0 in. × 93.9 in. × 57.9 in.)	2,815 mm × 2,384 mm × 1,469 mm ( 110.9 in. × 93.9 in. × 57.9 in.)	2,815 mm × 3,399 mm × 1,469 mm ( 110.9 in. × 133.9 in. × 57.9 in.)	2,815 mm × 3,999 mm × 1,469 mm ( 110.9 in. × 157.5 in. × 57.9 in.)
Weight		487 kg ( 1,074 lb.)	455 kg ( 1,004 lb.)	667 kg ( 1,471 lb.)	863 kg ( 1,903 lb.)	959 kg ( 2,115 lb.)
Environment	During operation(*1)	Temperature: 20 to 32 °C (68 to 89.6 °F), Humidity: 35 to 80 %RH (no condensation)
	Not operating	Temperature: 5 to 40 °C (41 to 104 °F), Humidity: 20 to 80 %RH (no condensation)
Included Items		Power cord, cleaning liquid, drain bottle, User’s Manual, software (VersaWorks, Roland DG Connect), etc.

1 Operating environment (Use the machine in an operating environment within these ranges.)

CO-640

Printable Width 1,612mm
Printable length options 1,500 mm, 2,500 mm, 3,050 mm
Max Print Height 200 mm
Available Ink CMYK, Gloss, White, Red, Orange, Primer
Bed Options Flatbed | Belt1

CO-300

Printable Width 749mm
Printable length options 1,500 mm
Max Print Height 200 mm
Available Ink CMYK, Gloss, White, Red, Orange, Primer
Bed Options Flatbed | Belt1

Read less...

To contact Prytec Solutions about UV Printer Machine 200 mm | VersaOBJECT CO Series use Get a quote.

Datasheet_VersaOBJECT_CO_Series_DAS_web(0.63MB)
