Terex - Insulated Truck Mounted EWP - TL55 - 18.8m Get latest price

Read more...

To contact Lift Industries about Terex Insulated Truck Mounted EWP - TL55 - 18.8m use Get a quote.

Introducing the Terex TL55 Insulated EWP

Engineered for performance, safety, and versatility, the Terex TL55 is a truck-mounted insulated elevating work platform (EWP) purpose-built to meet the demands of high-voltage environments and elevated access applications. Compact yet robust, the TL55 delivers exceptional reach and manoeuvrability without compromising stability or operator comfort.

This model is widely adopted across key sectors—including arboriculture, utilities, infrastructure maintenance, and construction—thanks to its reliable operation and compliance with Australian standards (AS 2550.10). The TL55 features a fully insulated boom system rated to 66kV, making it ideal for tasks near or around electrical assets.

Operators benefit from intuitive, ergonomically designed controls that enable precise boom articulation and smooth platform positioning. The system’s responsive hydraulics and advanced safety interlocks reduce setup time and enhance jobsite efficiency, helping crews stay productive with minimal downtime.

Whether you're clearing vegetation near power lines, conducting pole-top maintenance, or installing overhead infrastructure, the Terex TL55 offers a dependable solution that supports safe, streamlined operations in the field.

Standard Inclusions

• Working Height 18.8 meters

• Outreach 11.7 meters

• Platform capacity of up to 272kg, (Optional 350kg with Radio Remote)

• End Mount 610mm x 1220mm x 1070mm, Two-Person Platform (larger Platform available)

• Insulation rating 66 kV

• Control-Plus 4-Function Single Stick Control at Platform

• Continuous unrestricted worm gear rotation

• Insulation rating 66 kV

• Rectangular, Bi-Axial epoxy resin, filament wound fiberglass booms

• Individual lever lower Controls

• Hydraulic platform levelling system

• 180° hydraulic platform rotator

• Hydraulic tool outlets at platform and chassis

• Auxiliary power let down system

• Hydraulic boom stow latch

• Fiberglass telescopic section boom

• Fiberglass boom insert

• Padded lower boom rest

• Boom Stabiliser / interlock

• Engine Start/Stop

• Platform cover

The TL55 also includes hydraulic tool outlets at  the platform , an auxiliary power let down system, and individual lever lower controls for added convenience. In addition, the TL55 offers customization options such as a larger platform, smart PTO electric drive, and a full dual remote control for boom movement.

As there are various chassis options and features available, we prefer to provide a tailored quote based on your specific requirements. Contact us today, and we'll be happy to offer a quote that best suits your needs.
