PCR31
The PCR31 is a versatile beam and plate coping system that combines structural steel and plate processing in one workflow. It performs notches, holes, weld preps, beam splitting, scribing, and marking on up to three faces of H-beams, channels, angles, HSS, and plate. It processes plates up to 60" wide with integrated torch height control and automatic calibration. A non-contact 3D vision system adapts to material deviations, while DSTV/DXF file import ensures seamless data transfer from detailing software such as Tekla, SDS/2, and Graitec.

PCR41
The PCR41 is a compact, high-definition robotic plasma cutting solution for structural steel fabricators. It delivers four-face processing for copes, notches, holes, and markings on all sides of the material. Designed for space efficiency, it offers flexible layout configurations and processes DSTV/NC1 files directly without macros. Equipped with a laser measurement system and dual rotary encoders, it automatically adjusts for material deviations. The PCR41 cuts I-beams up to 30", HSS up to 16" × 16", channels, angles, and plates.

PCR42
The PCR42 represents Prodevco’s most advanced robotic coping system, combining 7-axis motion control, robotic precision, and laser vision technology. It performs copes, notches, weld preps, and markings on all four faces of beams, angles, HSS, plates, and optional round tubes. Its laser and rotary encoder systems detect and compensate for dimensional deviations, ensuring exceptional accuracy. High throughput and intelligent nesting allow multiple parts to be processed from raw stock, reducing waste. With a compact footprint and flexible configuration, the PCR42 achieves productivity gains of up to 10× in demanding fabrication environments.
